| 節省地板空間50%以上 |
|
| |
|
TB-W型精巧鍋爐與同級廠牌比較，可以節省一半以上的空間，這樣的結果可以讓您節省日益增加的建築成本消耗。這種直接反映節省成本之經濟效益，是我們最大的優點。 |
|
| |
可以不需考慮尺寸空間配置，直接且快速淘汰一些老舊鍋爐 |
|
| |
|
TB-W型外型僅1.2m寬，可以消除打掉牆的成本，同時他的簡易安置，可以淘汰那些老舊，沒效率的鍋爐，這種簡便換裝，大大減少原本已定型廠房配置因換裝新鍋爐而面臨因修改廠房而停擺之窘況。 |
|
| |
重量減輕40%以上 |
|
| |
|
TB-W型的重量遠低於同級他牌鍋爐，因此在裝運過程，不但輕便又減少裝運成本，更可減少固定支撐的開銷。 |
|
| |
裝箱方式快速連結 |
|
| |
|
東興實業有限公司48年來一貫秉持在安裝費上節省時間與金錢概念。因此，才會發明這項創舉。每一組件都經過完全組裝測試，多項專利，並在運用前備妥燃料水，電氣品方可運作。 |
|
| |
全新低噪音分貝 |
|
| |
|
TB-W型不含燃燒室氣源，即直接驅動的非震動離心式葉片，這就是TB-W型極靜音運轉之秘密武器。即使燃燒機在高段火力下TB-W型運轉最大噪音值僅達90Db(分貝)這是依照醫院、療養院、學校、教堂、公寓等噪音標準設計的。 |
|
| |
|
|
| |
指明高效率強制通風點火之TB-W型輕巧鍋爐
|
|
| |
逆火式之點火方式是針對TB-W型之紮時所設計。當熱氣巡迴爐體長度然後逆轉回來，提供更大的爐體單位體積熱能釋放，及點火的爐體單位體積熱能吸收，這是同級鍋爐所不及的，且第三級最後逆轉可以向下的固定區域產生熱氣亂流以提昇管路內之水對流效率。 |
|
| |
此外TB-W型具有迅速循環效果，能有效提昇熱傳能立即快速啟動循環特性，末端負載反映迅速遠大過他牌之設計。 |
|
| |
|
|
| |
經驗豐富之燃燒機 |
|
| |
|
TB-W型已歷經數年研究及測試，其低壓噴霧燃燒機可以使用2號燃油、天然氣、液化瓦斯或混合燃料，可以有效轉換成有用能量，提昇燃油效率，降低燃油消耗。經過TB-W型有效控制，使得不同燃油之轉換可以任意調整。 |
|
| |
清除煙灰不需關斷 |
|
| |
|
煙灰產生會降低熱傳效率，浪費能源，因此tTB-W型裝有標準型吹煙器，能有效控煙灰產生，不殘留、不必關斷，以便誏鍋爐保持最佳性能狀態。 |
|
| |
|
|
| |
TB-W型待命為您服務
|
|
| |
如果你的鍋爐是低效率，即表示您在浪費能源及金錢。
|
|
Indicate and Purchase TB-W Model Refind Boiler of High Performance, with Enforced Ventilating Ignition Type
|
|
| |
TB-W型紮實的設計，可以保持最高之效能。將燃料轉換成蒸汽，並徹底改變您對鍋爐之刻板印象。 |
|
| |
TB-W型之寬度平展有1.2m寬度，有足夠的空間通過廠房走道及門框，它雖迷你，但高效性能卻傲視他牌，其有效蒸發量達1,000－6,000ka/hr，設計壓力達10kg－50kg，並且可選燃料設備使用配置，TB-W型是小而省，同時低噪音設計最大僅90dba，在裝運上配備齊全。 |
|
| |
低維修 |
|
| |
|
最少的耐火材料： |
|
| |
|
TB-W型利用水牆隔膜作燃燒室之煙道，可以減少95％之耐火材料之耗費，TB-W型僅將耐火材料侷限使用在燃燒之喉部至爐體版面上。這個結果不但實實在在減少耐火材料損耗，並降低維修汰舊耐火材料之成本。 |
|
| |
高性能水牆隔膜設計 |
|
| |
|
水牆隔膜設應用已廣泛在變電所上TB-W型就是利用此高效率性能將其應用在TB-W型上，而TB-W型之壓力管路均通過空氣測漏，以確保燃燒機之氣體未洩漏至鍋爐塞。 |
|
| |
|
|
| |
工廠之啟動與服務 |
|
| |
為了確保您所購買之TB-W型鍋爐性能無誤，我們每一位接受過專業訓練之技師，會檢測每一套件及整體結構，並測試每一運轉狀況，並讀出末端負載之CO2讀數。我們並訓練您的操作員小心使用與維修此裝備。 |
|
 |
| |
It saves floor space for more than 50% |
|
| |
|
TB-W Model Refind Boiler, if compared with the brands of the same grade, can save more than 50% of space. This result can help you to save the gradually increased construction cost. This kind of feature of direct reflection of economic performance in cost saving is our best advantage. |
|
| |
One can avoid consideration of dimension and space allocation, directly and repidly get rid of some old boilers. |
|
| |
|
The facade of TB-W Model Refined Boiler is only 1.2m wide, able to eliminate the cost of removing part of wall. Besides, its convenience in allocation can get rid of those old and nonefficient boilers. This kind of simple remodeling can largely reduce the dilemma of temporary auspension of operation due to remodeling of plant building for the originally fixed plant building layout because of replacement of a new boiler. |
|
| |
Weight to reduce more than 40% |
|
| |
|
The weight of TB-W Model is far lower than the boilers of other brands of the same grade. Therefore, during the handling process, it is not only light, convenient, but also less in handling cost. It can further reduce the expense of the stabilizing support. |
|
| |
Container Packaging Manaer, Rapid Connection |
|
| |
|
Tung Hsing Industrial Co., Ltd. Has maintained its concept of saving time and money in installation cost for 48 years. Therefore, it invents this invention. Each component has been through complete fabrication tast, with numerous patents and fuel water is duly prepared prior to operation, so that the electrical product can be operated. |
|
| |
Brand New, Low Noise Decibel |
|
| |
|
The TB-W Model does not contain air source for the combustion chamber; that is, directly drive the nonvibrationg eccentric type of blade. This is the secret weapon of TB-W Model in extremely silent rotaiton. Even if the combustion engine is under strong fire, the maximum noise value of the rotation of TB-W Model attains only 90dba which is designed in accordance with such nosie standard of hospital, treatment hospital, school, church and apartment, etc. |
|
| |
|
|
| |
| |
|
The reverse-fire type ignition method of TB-W Model Refined Boiler is solidly designed for TB-W Model. As hot air tour around the boiler frame length and then returns back, it provides larger heat energy release than the single dimension of boiler frame and larger heat energy absorption than the single dimension of boiler frame which is uncompetitive by other boilers of the same grade. In addition, the last loop of grade 3 can produce chaotic heat air flow downward at the fixed ares to upgrade the water convaction parformance in pipe.
Besides, TB-W Model is provided with rapid circulation effect, able to effectively upgrade the immediate pump start feature of heat energy. The rapid terminal load reflection far exceeds the design of other brands. |
|
| |
|
|
| |
Combustion Engine with Rich Experience |
|
| |
|
The TB-W Model has been through research and test for several years. Its low-pressure mist spray combustion engine can use number 2 fuel, natural gas, liguefied gas, or mixed fuel, able to be affectively converted into useful energy, upgrade fuel performance, reduce fuel consumption. |
|
| |
|
Through effective control of TB-W Model, its makes the conversion of different fuels to be able to be adjusted rapidly. |
|
| |
No Need of Switch Off While Cleaning Sludge |
|
| |
|
The ash sludge will reduce heat conduction afficiency, waste energy resource. Therefor, TB-W Model is provided with a standard type of smoke blower, able to effectively control the production of ash sludge, without residuals, nor a need of switching off, to facilitate the boiler to manintain its best property and status. |
|
| |
| |
TB-W Model Resdy to Provide Service for You |
|
| |
If your boiler is of low performance, it indicates you are wasting energy resouce and money. |
|
| |
|
The solid design of TB-W Model can maintain the top perormance, by converting fuel into steam and thoroughly changing your sterectyped impression of boiler. The extended width of TB-W Model is 1.2m, with sufficient space to pass by plant building corridor and doorsile. Though it is mini in size, yet its high performance is prominent while compared with that of other brands. Its effective evaporating quantity attains 1,000-6,000ka/hr, with design pressure to attain 10kg-50kg, and one can select fuel equipment for service composition. TB-W Model is small and economic. Meanwhile, the maximum noise is designed to be only 90 dba, with comprehensive equipment in rotation. |
|
| |
Low Maintenance |
|
| |
|
The least fire-proof material: |
|
| |
|
TB-W Model, by means of water wall diaphragm as the flue gas chute, able to reduce the consumption of 95% of fireproof material. On the other hand, TB-W Model only limits the fireproof matarial to the throat part of the combustion engine to furnance board. This result does not only faithfully reduce the consumption of fireproof material, but also reduces the cost of maintenance cost for replacement of fireproof material. |
|
| |
High Performance of Water Wall Diaphragm Design |
|
| |
|
The water wall diaphragm application has been comprehensive in substations. TB-W Model uses this high-performance property by applying it to TB-W Model.Besides, the pressure pipes of TB-W Model all pass air leakage test, to ensure the air in a combustion engine to be free from disclosure to the boiler piston. |
|
| |
|
|
| |
Plant Start and Service
|
|
| |
In order to ensur the property of the TB-W Model boiler you purchase to be correct without an error, each of our professional engineer through specialized training will inspect each sleeve part and the integral structure, and test each rotation status, loading CO2 reading of the virus appearance cerminals. We will also train your operators to be careful in application and maintenance for this equipment. |
